Giada D610
Comet Lake High-end Digital Signage Player.

Belangrijkste eigenschappen
- 1 x DP, 1 x HDMI, Supporting 4K Display
- 2 x SO-DIMM DDR4 Memory, Up to 32GB
- 1 x M-key M.2 (2242/2280) for SATA/NVMe
- 1 x Full-size Mini-PCIe for mSATA/WiFi/3G/4G

Specificaties
Processor
CPU: Intel?Core? i5-10210U
Chipset: SoC
BIOS: AMI Source Code

Memory
Type: DDR4-2400MHz
Socket: 2 x SO-DIMM
Max Size: 32GB

Graphics
GPU: Intel? 10th Gen. UHD Graphics
Graphic Engine: Direct3D 2015, OpenGL 4.5, OpenCL 2.1
Interface: 1 x DP (Max.4096 x 2304 @60Hz), 1 x HDMI (Max.4096x2304 @60Hz), 1 x HDMI (Max.4096x2304 @24Hz)

Network
Controller: Realtek 8111H Gigabit Ethernet
Interface: 1 x RJ45

I/O
USB: 5 x USB 3.2 Gen2 (10 Gbps)
Serial Port: 1 x RS232
Audio: 1 x MIC-IN, 1 x AUDIO-OUT
MiniPCIe: 1 x Full-size Mini-PCIe for mSATA/WiFi/3G/4G
M.2(2230): 1 x M.2(2230) for WiFi
SIM Card: 1 x SIM-Slot
TPM: Infineon TPM 2.0

Storage
M.2: 1 x M.2(2242/2280) for SSD

JAHC
WatchDog Timer: 0~255 Second Time Out Support
Auto Power On: Power Activated Automatically Start
IR remote Control: By IR Controller for Power On
RTC: Set Up Independently Every day, A Week as a Cycle
Wake On Lan: Yes

Operation System Supported
Windows: Windows 10(64-Bit)
Linux: Support

Power
Power Type: DC-IN
Power Adapter: 19V / 3.42A

Mechanical
Dimensions: 189.6 x 148.3 x 26 mm
Construction: Metal
Mounting: Desk/Wall Mounting and VESA Mounting Kit (JZ183)
Color: Black

Environment
Operating Temperature: 0?~40? (32 ?~104?) @ 0.7 m/s Air Flow
Relative Humidity: 95% @ 40? (non-condensing)

Certification
Certification: CE, FCC Class B, CCC

License
The Adopted Trademarks HDMI,HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
